Panel Brand：BOE
Panel Model：HM150X01-101
Panel Size：15.0 inch
Panel Type：a-Si TFT-LCD, LCM
Resolution：1024(RGB)×768 , XGA
Pixel Format：RGB Vertical Stripe
Display Area：304.128(W)×228.096(H) mm
Bezel Opening：307.4(W)×231.3(H) mm
Outline Size：326.5(W)×253.5(H)×11.9(D) mm
Surface：Antiglare (Haze 25%), Hard coating (3H)
Brightness：300 cd/m2 (Typ.)
Contrast Ratio：700:1 (Typ.) (TM)
Viewing Angle：80/80/70/60 (Typ.)(CR≥10)
Display Mode：TN, Normally White, Transmissive
Best View on：-
Response Time：8 (Typ.)(Tr+Td)
Display Colors：16.2M 60%(CIE1931)
Lamp Type：7S4PWLED, 30K hours, With LED Driver
Frequency： 60Hz
Touch Screen：Without
Panel Weight： 1.20Kgs (Max.)
Application： Industrial Application,
Signal Interface： LVDS (1 ch, 8-bit), 20 pins , Connector
Input Voltage：3.3V (Typ.)
Environment： Operating Temp.: 0 ~ 60 °C ; Storage Temp.: -20 ~ 70 °C：：
We use the following logistics services to deliver your order:
Yunexpress DDP: All customs duties and taxes are included. Delivery takes 6-12 working days.
DHL, UPS, FedEx: Delivery takes 2-4 working days.
Product condition: Brand New We can provide customized testing video upon request.
