Manufacturer：NLT
Model Name：NL10276AC30-53D
Screen Size：15.0 inch
Screen Type：LCM,a-Si TFT-LCD
Pixel Number：1024(RGB)×768 (XGA)
Arrangement：RGB Vertical Stripe
Active Area(mm)： 304.128 × 228.096 (H×V)
Outline(mm)：326.5 × 253.5× 6.8 (H×V×D)
Bezel Area(mm)： 307.4 × 231.3 (H×V)
Treatment： Antiglare, Hard coating (3H)
Luminance：500 cd/m2 (Typ.)
Contrast Ratio：600 : 1 (Typ.) (TM)
Viewing Angle： 80/80/80/80 (Typ.)(CR≥10)
Response： 3/5 (Typ.)(Tr/Td) ms
Good View at： 6 o’clock
Work Mode： TN, Normally White, Transmissive
Color Depth：262K/16.2M 60%(CIE1931)
Backlight：WLED, With LED Driver
Mass： TBD
Used for： Industrial Application,
Refresh Rate：60Hz
Touchscreen：Without
Signal Type： LVDS (1 ch, 6/8-bit), Connector , 30 pins
Voltage Supply：3.3V (Typ.)
Max. Ratings： Storage Temp.: -20 ~ 70 °COperating Temp.: -20 ~ 70 °C
