Brand：NEC
Model：NL6448BC18-011 Compatible
Diagonal Size：5.7 inch
Type：a-Si TFT-LCD, LCM
Pixel Format：640(RGB)×480[VGA]
Configuration：RGB Vertical Stripe
Active Area：116.16(H)×87.12(V) mm
Outline Dim.：135(H)×104.6(V)×10.9(D) mm
Bezel Area：120.2(H)×91.2(V) mm
Treatment：Clear, Hard coating (3H)
Luminance：400 cd/m2 (Typ.)
Contrast Ratio：850:1 (Typ.) (TM)
View Direction：-
Response Time：3/15 (Typ.)(Tr/Td)
Viewing Angle：80/80/80/80 (Typ.)(CR≥10)
Operating Mode：TN, Normally White, Transmissive
Support Color：262K 60%(CIE1931)
Light Source：WLED[9S2P], 50K hours, W/O Driver
Weight： 160/170g (Typ./Max.)
Designed For： Industrial Application,
Frame Rate：60Hz
Touch Panel：Without
Interface Type： 33 pinsCMOS (1 ch, 6-bit), Connector
Power Supply：3.3V (Typ.)
Environment： Operating Temperature: -30 ~ 80 °C ; Storage Temperature: -30 ~ 80 °C ; Vibration Level: 2.0G (19.6 m/s2)
We use the following logistics services to deliver your order:
Yunexpress DDP: All customs duties and taxes are included. Delivery takes 6-12 working days.
DHL, UPS, FedEx: Delivery takes 2-4 working days.
Product condition: Brand New We can provide customized testing video upon request.
