Panel Brand：NEC
Panel Model：NL10276BC24-13
Panel Size：12.1 inch
Panel Type：a-Si TFT-LCD, LCM
Resolution：1024(RGB)×768 , XGA
Pixel Format：RGB Vertical Stripe
Display Area：245.76(W)×184.32(H) mm
Bezel Opening：249.0(W)×187.5(H) mm
Outline Size：280(W)×210(H)×13.7(D) mm
Surface：Clear, Hard coating (3H)
Brightness：400 cd/m2 (Typ.)
Contrast Ratio：600:1 (Typ.) (TM)
Viewing Angle：70/70/45/55 (Typ.)(CR≥10)
Display Mode：TN, Normally White, Transmissive
Best View on：6 o'clock
Response Time：8/25 (Typ.)(Tr/Td)
Display Colors：262K/16.7M 40%(CIE1931)
Lamp Type：2 pcsCCFL, Optional
Frequency：60Hz
Touch Screen：Without
Panel Weight： 750/780g (Typ./Max.)
Application： Industrial Application,
Signal Interface： LVDS (1 ch, 6/8-bit), 20 pins, Connector
Input Voltage：3.3V (Typ.)
Environment：Operating Temp.: -10 ~ 70 °C ;Storage Temp.: -20 ~ 80 °C; Vibration Level: 2.0G (19.6 m/s2)
We use the following logistics services to deliver your order:
Yunexpress DDP: All customs duties and taxes are included. Delivery takes 6-12 working days.
DHL, UPS, FedEx: Delivery takes 2-4 working days.
Product condition: Brand New We can provide customized testing video upon request.
