Brand：PVI
Model：PM100WX2
Diagonal Size：10.0 inch
Type：a-Si TFT-LCD, LCM
Pixel Format：800(RGB)×480[WVGA]
Configuration：RGB Vertical Stripe
Active Area：216(H)×129.6(V) mm
Outline Dim.：232(H)×144.3(V)×6.5(D) mm
Bezel Area：220.0(H)×133.6(V) mm
Treatment：Antiglare
Luminance：350 cd/m2 (Typ.)
Contrast Ratio：400:1 (Typ.) (TM)
View Direction：-
Response Time：15/25 (Typ.)(Tr/Td)
Viewing Angle：50/50/15/35 (Typ.)(CR≥10)
Operating Mode：TN, Normally White, Transmissive
Support Color：262K
Light Source：CCFL[1 pcs], 30K hours, W/O Driver
Weight： 339±10g
Designed For： Automotive Display, Industrial Application,
Frame Rate：60Hz
Touch Panel：Without
Interface Type： 60 pinsParallel RGB (1 ch, 6-bit), FPC
Power Supply：3.3/3.3/9.5/27.0/-10.0V (Typ.)(VCC/VDD/VDD2/VGH/VEE)
Environment： Operating Temperature: -20 ~ 80 °C ; Storage Temperature: -30 ~ 80 °C
