| 外形尺寸 | ATX |
|---|---|
| 乙太網路晶片組 | Intel 82541 |
| 視訊晶片組 | Intel 865G |
| 音訊 | Audio Output:AC97 audio interface (requires an audio extension module P/N: PCA-AUDIO-00A1E) |
| BIOS | Award 4 Mbit FWH |
| 板類型 | 全尺寸 |
| 頻道 | SATA-2 EIDE-2 (Max. 4 devices) |
| 晶片組 | Intel 865G + ICH5 |
| 連接器 | RJ-45 x 2 |
| 控制器 | Chipset integrated VGA controller LAN 1: Intel 82562EZ (FE); Intel 82547GI (Gigabit, CSA) LAN 2: Intel 82541PI (Gigabit) |
| 中央處理器 | Intel Pentium 4 Intel Celeron D Intel Celeron |
| 尺寸 | 338 x 122 mm (13.3″ x 4.8″) |
| 環境 | 0 ~ 60° C (32 ~ 140° F), depends on CPU’s speed |
| FDD | 1 |
| FSB | 400/533/800 MHz |
| 輸入 | 10/100Base-T; 10/100/1000Base-T (optional) |
| ISA | HISA (ISA high drive) |
| L2 快取記憶體 | 256 KB/ 512 KB/ 1 MB 256 KB 128/256 KB |
| Max Capacity | 4 GB |
| Max Data Transfer Rate | 150 MB/s |
| Max. Speed | 3.06 GHz (533 FSB) 3.4 GHz (800 FSB) * Vcore 1.75 V CPU (Willamette) not supported 3.06 GHz 2.8 GHz |
| 平行 | 1 (SPP/EPP/ECP) |
| PCI | 32-bit/33 MHz |
| 耗電量 | Pentium 4 3.0 GHz (800 MHz FSB), 4 x 512 MB DDR 400 SDRAM +5 V -5 V +12 V -12 V 6.53 A 0.1 A 4.6 A 0.2 A |
| 處理器 | Intel Pentium 4 |
| PS/2 | 1 |
| 序列 | 2 (RS-232) |
| 插座 | 184-pin DIMM x 4 |
| 技術 | Dual Channel DDR 266/333/400 SDRAM |
| USB | Max. 6 (USB 2.0 compliant), 4 ports on board for G2 versions |
| VRAM | Dynamically shared system memory, 8 ~ 64 MB |
| 看門狗計時器 | Output Interrupt: system reset IntervalProgrammable: 1 ~ 255 sec. |
