BOE HV320WXC-100 LCD panel

Panel Brand：BOE
Panel Model：HV320WXC-100
Panel Size：31.5 inch
Panel Type：a-Si TFT-LCD, LCM
Resolution：1366(RGB)×768 , WXGA
Pixel Format：RGB Vertical Stripe
Display Area：697.685(W)×392.256(H) mm
Bezel Opening：-
Outline Size：760(W)×450(H) mm
Surface：Antiglare (Haze 10%), Hard coating (3H)
Brightness：450 cd/m2 (Typ.)
Contrast Ratio：1200:1 (Typ.) (TM)
Viewing Angle：89/89/89/89 (Typ.)(CR≥10)
Display Mode：ADS, Normally Black, Transmissive
Best View on：Symmetry
Response Time：8 (Max.)(G to G)
Display Colors：16.7M 72%(CIE1931)
Lamp Type：4 pcsCCFL, 50K hours, With Inverter
Frequency：60Hz
Touch Screen：Without
Panel Weight： 5.30Kgs (Typ.)
Application： TV Sets,
Signal Interface： LVDS (1 ch, 8-bit), 30 pins, Connector
Input Voltage：12.0V (Typ.)
Environment：Operating Temp.: 0 ~ 50 °C ;Storage Temp.: -20 ~ 60 °C
