Panel Brand：AU Optronics
Panel Model：B084SN02 V0
Panel Size：8.4 inch
Panel Type：a-Si TFT-LCD, LCM
Resolution：800(RGB)×600 , SVGA
Pixel Format：RGB Vertical Stripe
Display Area：170.4(W)×127.8(H) mm
Bezel Opening：173.8(W)×131.2(H) mm
Outline Size：198.2(W)×143.6(H)×7.6(D) mm
Surface：-
Brightness：150 cd/m2 (Typ.)
Contrast Ratio：350:1 (Typ.) (TM)
Viewing Angle：60/60/40/40 (Typ.)(CR≥10)
Display Mode：TN, Normally White, Transmissive
Best View on：-
Response Time：10/25 (Typ.)(Tr/Td)
Display Colors：262K
Lamp Type：1 pcsCCFL, 10K hours, Without Driver
Frequency：-
Touch Screen：Without
Panel Weight： 210±10g
Application： Industrial Application,
Signal Interface： LVDS (1 ch, 6-bit), 20 pins, Connector
Input Voltage：3.3V (Typ.)
Environment：Operating Temp.: 0 ~ 50 °C ;Storage Temp.: -20 ~ 60 °C
