AUO B101EW02 V0 LCD panel replacement for Laptop

Brand：AUO
Model：B101EW02 V0 (AUO20D5) 1 Compatible
Diagonal Size：10.1 inch
Type：a-Si TFT-LCD， LCM
Pixel Format：1280(RGB)×720[WXGA]
Configuration：RGB Vertical Stripe
Active Area：222.72(H)×125.28(V) mm
Outline Dim.：235(H)×143.2(V)×5.2(D) mm
Bezel Area：-
Treatment：Glare (Haze 0%)
Luminance：200 cd/m2 (Typ.)
Contrast Ratio：500:1 (Typ.) (TM)
View Direction：6 o'clock
Response Time：12/4 (Typ.)(Tr/Td)
Viewing Angle：45/45/15/35 (Typ.)(CR≥10)
Operating Mode：TN， Normally White， Transmissive
Support Color：262K 45%(CIE1931)
Light Source：WLED， 12K hours， With LED Driver
Form Style： Wedge (PCBA Bent， Depth ≥5.2mm)
Designed For： Laptop,
Frame Rate：60Hz
Touch Panel：Without
Interface Type： 40 pinsLVDS (1 ch， 6-bit)， Connector
Power Supply：3.3V (Typ.)
Environment： Operating Temperature: 0 ~ 50 °C ; Storage Temperature: -20 ~ 60 °C
