Brand：CPT
Model：CLAA100XA22XV
Diagonal Size：10.0 inch
Type：a-Si TFT-LCD， LCM
Pixel Format：1024(RGB)×768[XGA]
Configuration：RGB Vertical Stripe
Active Area：202.752(H)×152.064(V) mm
Outline Dim.：-
Luminance：-
Contrast Ratio：800:1 (Typ.) (TM)
View Direction：Symmetry
Response Time：25 (Typ.)(Tr+Td)
Viewing Angle：80/80/80/80 (Typ.)(CR≥10)
Operating Mode：HFFS， Normally Black， Transmissive
Support Color：262K/16.2M 50%(CIE1931)
Light Source：WLED， 20K hours， W/O Driver
Weight： –
Designed For： Pad & Tablet,
Frame Rate：60Hz
Touch Panel：Without
Interface Type： 40 pinsLVDS (1 ch， 6/8-bit)， FPC
Power Supply：3.3/13/18/-6V (Typ.)(VDD/AVDD/VGH/VGL)
Environment： Operating Temperature: -20 ~ 60 °C ; Storage Temperature: -30 ~ 70 °C
We use the following logistics services to deliver your order:
Yunexpress DDP: All customs duties and taxes are included. Delivery takes 6-12 working days.
DHL, UPS, FedEx: Delivery takes 2-4 working days.
Product condition: Brand New We can provide customized testing video upon request.
