Manufacturer：AUO
Screen Size： 9.0 inch
Pixel Number： 800(RGB)×480(WVGA)
Active Area(mm)：198 × 111.696 (H×V)
Bezel Area(mm)：201.0 × 114.7 (H×V)
Luminance：300 (Typ.)(cd/m2)
Viewing Angle：70/70/50/70 (Typ.)(CR≥10)
Good View at：6 o'clock
Color Depth：16.7M
Mass： 255g (Typ.)
Refresh Rate：60Hz
Model Name：G090VTN02.0
Screen Type：LCM ,a-Si TFT-LCD
Arrangement：RGB Vertical Stripe
Outline(mm)： 211.1 × 128.4 × 7.1 (H×V×D)
Treatment：Antiglare, Hard coating (3H)
Contrast Ratio： 500 : 1 (Typ.) (TM)
Work Mode： TN, Normally White, Transmissive
Response：10/15 (Typ.)(Tr/Td) ms
Backlight： WLED , 20K hours , With LED Driver
Used for： Industrial Application,
Touchscreen：Without
Signal Type：TTL (1 ch, 8-bit), Connector, 50 pins
Voltage Supply： 3.3V (Typ.)
Max. Ratings： Storage Temp.: -30 ~ 80 °C Operating Temp.: -20 ~ 75 °C
