Manufacturer：AUO
Model Name：G190EG01 V2
Screen Size：19.0 inch
Screen Type：LCM ,a-Si TFT-LCD
Pixel Number：1280(RGB)×1024 (SXGA)
Arrangement：RGB Vertical Stripe
Active Area(mm)： 376.32 × 301.06 (H×V)
Outline(mm)：396 × 324 (H×V×D)
Bezel Area(mm)： 380.32 × 305.06 (H×V)
Treatment： Antiglare, Hard coating (3H)
Luminance：450 cd/m2 (Typ.)
Contrast Ratio：1000 : 1 (Typ.) (TM)
Viewing Angle： 85/85/80/80 (Typ.)(CR≥10)
Response： 3.6/1.4 (Typ.)(Tr/Td) ms
Good View at： 6 o’clock
Work Mode： TN, Normally White, Transmissive
Color Depth：16.7M
Backlight：4 pcsCCFL, 50K hours, No Driver
Mass： 2.40Kgs (Typ.)
Used for： Industrial Application,
Refresh Rate：60Hz
Touchscreen：Without
Signal Type：LVDS (2 ch, 8-bit), Connector, 30 pins
Voltage Supply：5.0V (Typ.)
Max. Ratings：Storage Temp.: -20 ~ 60 °C Operating Temp.: 0 ~ 50 °C
We use the following logistics services to deliver your order:
Yunexpress DDP: All customs duties and taxes are included. Delivery takes 6-12 working days.
DHL, UPS, FedEx: Delivery takes 2-4 working days.
Product condition: Brand New We can provide customized testing video upon request.
