| System Chipset | AMD LX800 |
| Form Factor | ATX |
| Ethernet Chipset | Realtek RTL8100C |
| Video Chipset | AMD Geode LX800 |
| Audio | Realtek ALC203 with AC’97 Codec |
| BIOS | AWARD |
| CPU | On board AMD® Geode™ LX800(500MHz) processor |
| Digital I/0 | 8-bit digital I/O, 4 input/ 4 output by super I/O |
| Dimensions | 115 mm x 165 mm |
| Display Interface | VGA integrated in AMD® LX800, 24-bit single channel TTL , 18-bit single channel LVDS |
| Ethernet | 10/100Mbps Realtek RTL8100C chipset |
| Expansions | 1 x PC/104-Plus |
| Humidity | Operating: 5% ~ 95%, non-condensing |
| I/O Interface | 4 x USB 2.0, 2 x SATA with ALI M5283 RAID 0,1 function support, 1 x CF Type II, 1 x LPT, 6 x RS-232, 1 x RS-422/485, 1 x PS/2 for KB/MS, 1 x IDE |
| Infrared Interface | 1 x Infrared Interface by pin header |
| Power Consumption | 12V@ 0.92A (AMD® LX800 with DDR 400MHz, 256MB RAM) |
| Power Supply | 12V only, AT/ATX support |
| Processor | AMD Geode |
| Super I/O | W83627EHG |
| System Chipsets | AMD® Geode LX800 +AMD® CS5536 |
| System Memory | One 200-pin 400/333MHz DDR SDRAM SO-DIMM Supported (System max. 1GB) |
| Temperature | Operating: 0°C ~ 60°C (32 ~ 140° F) |
| Watchdog Timer | Software programable supports 1-255 sec. system reset |
| Weight | GW: 950 g; NW: 350 g |
