| Form Factor | PICMG ISAPlus: Design to enhance the ISA bus drive capability(64mA) |
|---|---|
| Audio | AC’97 CODEC |
| Board Type | Full Size |
| Bus | AGP 4X/8X |
| Chipset | Intel 865G + ICH5 |
| CPU | Socket-478 for Intel Pentium 4 with 533/800MHz FSB |
| Ethernet | 1x 10/100Mbps i82562ET Ethernet; 2x 10/100Mbps i82559 Ethernet (ROCKY-4786E2V) |
| Operating Humidity | 5~95%, non-condensing |
| Operating Temperature | 0 – 60°C (CPU need cooler) |
| Power Consumption | 5~95%, non-condensing, [email protected] (P4 3.3GHz FSB 800MHz; Dual channel DDR400 512mb SDRAM) |
| SSD | 1xCompact Flash Type ?socket |
| System Memory | Dual channel DDR 333/400 SDRAM socket support up to 2GB |
| Watchdog Timer | software programmable, support 1~255 second system reset |
