Brand：Chimei Innolux
Model：HJ070NA-13D1 Compatible
Diagonal Size：7.0 inch
Type：a-Si TFT-LCD， LCM
Pixel Format：1024(RGB)×600[WSVGA]
Configuration：RGB Vertical Stripe
Active Area：153.6(H)×90(V) mm
Outline Dim.：165.25(H)×104.65(V)×2.9(D) mm
Bezel Area：156.42(H)×92.80(V) mm
Treatment：Glare (Haze 0%)
Luminance：350 cd/m2 (Typ.)
Contrast Ratio：700:1 (Typ.) (TM)
View Direction：12 o'clock
Response Time：10/15 (Typ.)(Tr/Td)
Viewing Angle：75/75/75/70 (Typ.)(CR≥10)
Operating Mode：TN， Normally White， Transmissive
Support Color：262K/16.7M
Light Source：WLED[4S6P]， 20K hours， W/O Driver
Weight： 100g (Max.)
Designed For： MP4 PMP, MID UMPC, Pad & Tablet,
Frame Rate：60Hz
Touch Panel：Without
Interface Type： 39 pinsLVDS (1 ch， 6/8-bit)， FPC
Power Supply：3.3V (Typ.)
Environment： Operating Temperature: -20 ~ 60 °C ; Storage Temperature: -30 ~ 70 °C
We use the following logistics services to deliver your order:
Yunexpress DDP: All customs duties and taxes are included. Delivery takes 6-12 working days.
DHL, UPS, FedEx: Delivery takes 2-4 working days.
Product condition: Brand New We can provide customized testing video upon request.
