Panel Brand：HannStar
Panel Size：10.1 inch
Resolution：1024(RGB)×600 , WSVGA
Display Area：220.416(W)×129.15(H) mm
Outline Size：234.6(W)×155.8(H)×3.5(D) mm
Brightness：180 cd/m2 (Typ.)
Viewing Angle：70/70/50/60 (Typ.)(CR≥10)
Best View on：6 o’clock
Display Colors：262K
Frequency： 60Hz
Shape Style：-
Panel Model：HSD100IFW3-A00
Panel Type：a-Si TFT-LCD , LCM
Pixel Format： RGB Vertical Stripe
Bezel Opening：-
Surface：Antiglare, Hard coating (3H)
Contrast Ratio：500:1 (Typ.) (TM)
Display Mode： TN, Normally White, Transmissive
Response Time：3/9 (Typ.)(Tr/Td)
Lamp Type：WLED, With LED Driver
Touch Screen：Without
Application： Digital Photo Frame, Portable DVD Player, Netbook PC,
Signal Interface： LVDS (1 ch, 6-bit), 30 pins , Connector
Input Voltage： 3.3V (Typ.)
Environment： Operating Temp.: 0 ~ 50 °C ;Storage Temp.: -20 ~ 60 °C
We use the following logistics services to deliver your order:
Yunexpress DDP: All customs duties and taxes are included. Delivery takes 6-12 working days.
DHL, UPS, FedEx: Delivery takes 2-4 working days.
Product condition: Brand New We can provide customized testing video upon request.
