Quantity:
Model P/N:G070ACE-L01
Brand:Innolux
Diagonal Size:7.0"
Resolution:800(RGB)×480, WVGA 133PPI
Brightness:500 cd/m² (Typ.)
Contrast Ratio:800:1 (Typ.) (TM)
Viewing Angle:89/89/89/89 (Typ.)(CR≥10)
Panel Type:a-Si TFT-LCD, LCM
Pixel Format:RGB Vertical Stripe
Active Area:152.4(W)×91.44(H) mm
Bezel Opening:154.4(W)×93.44(H) mm
Response Time:13/12 (Typ.)(Tr/Td)
Outline Size:170(W)×110(H) ×8.85(D) mm
Surface:Antiglare, Hard coating (3H)
Best View on:Symmetry
Display Colors:262K/16.7M 70% NTSC
Lamp Type:WLED , 50K hours , With LED Driver
Frequency:60Hz
Touch Screen:Without
Panel Weight:183±9g
Application:Industrial
Signal Interface:LVDS (1 ch, 6/8-bit) , 30 pins Connector
Input Voltage:3.3V (Typ.)
We use the following logistics services to deliver your order:
Yunexpress DDP: All customs duties and taxes are included. Delivery takes 6-12 working days.
DHL, UPS, FedEx: Delivery takes 2-4 working days.
Product condition: Brand New We can provide customized testing video upon request.
Description of your requirements:
