LG Display LP097QX2-SPAV LCD panel

Brand：LG Display
Model：LP097QX2-SPAV
Diagonal Size：9.7 inch
Type：a-Si TFT-LCD， LCM
Pixel Format：1536(RGB)×2048[QXGA]
Configuration：RGB Vertical Stripe
Active Area：147.456(H)×196.608(V) mm
Outline Dim.：160.3(H)×208.93(V) mm
Bezel Area：151.49(H)×200.62(V) mm
Treatment：Glare (Haze 0%)， Hard coating (3H)， Antireflection
Luminance：440 cd/m2 (Typ.)
Contrast Ratio：800:1 (Typ.) (TM)
View Direction：Symmetry
Response Time：30 (Typ.)(Tr+Td)
Viewing Angle：89/89/89/89 (Typ.)(CR≥10)
Operating Mode：IPS， Normally Black， Transmissive
Support Color：16.7M
Light Source：WLED， 10K hours， W/O Driver
Weight： 112g (Max.)
Designed For： Pad & Tablet,
Frame Rate：60Hz
Touch Panel：Without
Interface Type： 42 pinseDP (4 Lanes)， Connector
Power Supply：3.7V (Typ.)
Environment： Operating Temperature: 0 ~ 50 °C ; Storage Temperature: -20 ~ 60 °C
