LG Display LP116WH1-TLN1 LCD panel

Brand：LG Display
Model：LP116WH1-TLN1 (LGD02BE) 7 Compatible
Diagonal Size：11.6 inch
Type：a-Si TFT-LCD, LCM
Pixel Format：1366(RGB)×768[WXGA]
Configuration：RGB Vertical Stripe
Active Area：256.125(H)×144(V) mm
Outline Dim.：268.5(H)×162(V)×5.2(D) mm
Bezel Area：261.15(H)×148.34(V) mm
Treatment：Glare (Haze 0%)
Luminance：200 cd/m2 (Typ.)
Contrast Ratio：300:1 (Min.) (TM)
View Direction：6 o’clock
Response Time：16 (Typ.)(Tr+Td)
Viewing Angle：40/40/10/30 (Min.)(CR≥10)
Operating Mode：TN, Normally White, Transmissive
Support Color：262K
Light Source：WLED, 12K hours, With LED Driver
Form Style：Wedge (PCBA Bent, Depth ≥5.2mm)
Designed For： Laptop, Netbook PC,
Frame Rate： 60Hz
Touch Panel：Without
Interface Type： 40 pinsLVDS (1 ch, 6-bit), Connector
Power Supply：3.3V (Typ.)
Environment：Operating Temperature: 0 ~ 50 °C; Storage Temperature: -20 ~ 60 °C
