Manufacturer：JDI
Model Name：LPM055A138A
Screen Size：5.5 inch
Screen Type：LCM,LTPS TFT-LCD
Pixel Number：1440(RGB)×2560 (Quad-HD)
Arrangement：RGB Vertical Stripe
Active Area(mm)： 68.04 × 120.96 (H×V)
Outline(mm)：70.94 × 128.26× 1.5 (H×V×D)
Bezel Area(mm)： –
Treatment： Hard coating (3H)
Luminance：450 cd/m2 (Typ.)
Contrast Ratio：950 : 1 (Typ.) (TM)
Viewing Angle： 80/80/80/80 (Typ.)(CR≥10)
Response： 20 (Typ.)(Tr+Td) ms
Good View at： Symmetry
Work Mode： IPS, Normally Black, Transmissive
Color Depth：16.7M 70%(CIE1931)
Backlight：7S2PWLED, No Driver
Mass： 24.9g (Typ.)
Used for： Mobile Phone,
Refresh Rate：60Hz
Touchscreen：Without
Signal Type： MIPI (2 ch, 4 data lanes), Connector , 50 pins
Voltage Supply：1.8/5.0/-5.0V (Typ.)(VDDI/AVDD/AVEE)
Max. Ratings： Storage Temp.: -30 ~ 80 °COperating Temp.: -20 ~ 70 °C
We use the following logistics services to deliver your order:
Yunexpress DDP: All customs duties and taxes are included. Delivery takes 6-12 working days.
DHL, UPS, FedEx: Delivery takes 2-4 working days.
Product condition: Brand New We can provide customized testing video upon request.
