Panel Brand：SHARP
Panel Model：LQ035Q1DH01
Panel Size：3.5 inch
Panel Type：a-Si TFT-LCD, LCM
Resolution：320(RGB)×240 , QVGA
Pixel Format：RGB Vertical Stripe
Display Area：70.56(W)×52.92(H) mm
Bezel Opening：-
Outline Size：76.9(W)×63.9(H)×4.7(D) mm
Surface：Antiglare, Hard coating (2H)
Brightness：400 cd/m2 (Typ.)
Contrast Ratio：300:1 (Typ.) (TM)
Viewing Angle：45/45/20/55 (Typ.)(CR≥10)
Display Mode：TN, Normally White, Transmissive
Best View on：6 o’clock
Response Time：30/30 (Typ.)(Tr/Td)
Display Colors：262K
Lamp Type：7S1PWLED, Without Driver
Frequency： 60Hz
Touch Screen：Embeded (4-wire Resistive)
Panel Weight： 43.0g (Typ.)
Application： Digital Still Camera,
Signal Interface： Parallel RGB (1 ch, 6-bit) + SPI, 67 pins , FPC
Input Voltage：3.3/3.3V (Typ.)(VDDIO/VCI)
Environment： Operating Temp.: -10 ~ 70 °C ; Storage Temp.: -30 ~ 85 °C
