Brand：SHARP
Diagonal Size：6.5 inch
Pixel Format：800(RGB)×480[WVGA]
Active Area：144(H)×78.24(V) mm
Bezel Area：149.3(H)×83.45(V) mm
Luminance：380 cd/m2 (Typ.)
View Direction：6 o'clock
Viewing Angle：65/65/60/65 (Typ.)(CR≥5)
Support Color：262K
Weight：185g (Max.)
Frame Rate： 60Hz
Model：LQ065Y5DG01
Type：a-Si TFT-LCD ， LCM
Configuration：RGB Vertical Stripe
Outline Dim.： 157.2(H)×89.7(V)mm
Treatment：Antiglare
Contrast Ratio： 100:1 (Min.) (TM)
Response Time：30/50 (Typ.)(Tr/Td)
Operating Mode： TN， Normally White， Transmissive
Light Source： CCFL [1 pcs] ， 10K hours ， W/O Driver
Designed For： Automotive Display,
Touch Panel：Without
Interface Type： 65 pinsParallel RGB (1 ch， 6-bit)， FPC
Power Supply： 5/3.3/15/-12/-14.4/-17.4V (Typ.)(VSHA/VGHD/VDD/VEE/VCC/VSS)
Environment： Operating Temperature: -30 ~ 85 °C; Storage Temperature: -40 ~ 85 °C; Vibration Level: 2.9G (28.4 m/s2)
