SHARP LQ121S1LG74A LCD panel

Manufacturer：SHARP
Model Name：LQ121S1LG74A
Screen Size：12.1 inch
Screen Type：LCM ,a-Si TFT-LCD
Pixel Number：800(RGB)×600 (SVGA)
Arrangement：RGB Vertical Stripe
Active Area(mm)： 246 × 184.5 (H×V)
Outline(mm)：265 × 205× 10 (H×V×D)
Bezel Area(mm)： 257.3 × 188.1 (H×V)
Treatment： Hard coating (3H)
Luminance：450 cd/m2 (Typ.)
Contrast Ratio：800 : 1 (Typ.) (TM)
Viewing Angle： 80/80/60/80 (Typ.)(CR≥10)
Response： 30 (Typ.)(Tr+Td) ms
Good View at： –
Work Mode： TN, Normally White, Transmissive
Color Depth：16.7M 78%(CIE1931)
Backlight：WLED, 50K hours, With LED Driver
Mass： 550g (Max.)
Used for： Gaming,
Refresh Rate：60Hz
Touchscreen：Without
Signal Type：LVDS (1 ch, 8-bit), Connector, 30 pins
Voltage Supply：3.3V (Typ.)
Max. Ratings：Storage Temp.: -30 ~ 75 °C Operating Temp.: -10 ~ 75 °C
Packaging size: 35*30*7cm
Packaging weight: 1KG
DHL/Fedex/UPS Gross weight: 1.5KG
