SHARP LQ123K3LG01 LCD panel

Manufacturer：SHARP
Model Name：LQ123K3LG01
Screen Size：12.3 inch
Screen Type：LCM,a-Si TFT-LCD
Pixel Number：1280(RGB)×480 (DVGA)
Arrangement：RGB Vertical Stripe
Active Area(mm)：291.84 × 109.44 (H×V)
Outline(mm)： 312.4 × 130.4 (H×V×D)
Bezel Area(mm)：295 × 113.4 (H×V)
Treatment：Antiglare, Hard coating
Luminance：450 cd/m2 (Typ.)
Contrast Ratio：400 : 1 (Typ.) (TM)
Viewing Angle：65/65/50/60 (Typ.)(CR≥10)
Response：35 (Typ.)(Tr+Td) ms
Good View at：6 o’clock
Work Mode：TN, Normally White, Transmissive
Color Depth：262K/16.7M 61%(CIE1931)
Backlight：WLED, 70K hours, With LED Driver
Mass： 425g (Max.)
Used for： Gaming,
Refresh Rate：60Hz
Touchscreen：Without
Signal Type： LVDS (1 ch, 6/8-bit), Connector , 20 pins
Voltage Supply：3.3V (Typ.)
Max. Ratings： Storage Temp.: -30 ~ 75 °COperating Temp.: 0 ~ 75 °C
