SHARP LQ150X1LX91 LCD panel

Manufacturer：SHARP
Model Name：LQ150X1LX91
Screen Size：15.0 inch
Screen Type：LCM ,a-Si TFT-LCD
Pixel Number：1024(RGB)×768 (XGA)
Arrangement：RGB Vertical Stripe
Active Area(mm)： 304.128 × 228.096 (H×V)
Outline(mm)：326.5 × 253.5× 10.1 (H×V×D)
Bezel Area(mm)： 307.4 × 231.3 (H×V)
Treatment： Antiglare (Haze 3%), Hard coating (3H)
Luminance：270 cd/m2 (Typ.)
Contrast Ratio：1500 : 1 (Typ.) (TM)
Viewing Angle： 85/85/85/85 (Typ.)(CR≥10)
Response： 35 (Typ.)(Tr+Td) ms
Good View at： Symmetry
Work Mode： ASV, Normally Black, Transmissive
Color Depth：16.2M 70%(CIE1931)
Backlight：WLED, 35K hours, With LED Driver
Mass： 950g (Max.)
Used for： Industrial Application,
Refresh Rate：60Hz
Touchscreen：Without
Signal Type：LVDS (1 ch, 8-bit), Connector, 20 pins
Voltage Supply：3.3V (Typ.)
Max. Ratings：Storage Temp.: -25 ~ 65 °C Operating Temp.: -10 ~ 65 °C
