Manufacturer：SHARP
Model Name：LQ201U1LW32
Screen Size：20.1 inch
Screen Type：LCM,a-Si TFT-LCD
Pixel Number：1600(RGB)×1200 (UXGA)
Arrangement：RGB Vertical Stripe
Active Area(mm)： 408 × 306 (H×V)
Outline(mm)：436 × 335× 20.4 (H×V×D)
Bezel Area(mm)： 413.2 × 311.2 (H×V)
Treatment： Antiglare, Hard coating (2H)
Luminance：260 cd/m2 (Typ.)
Contrast Ratio：1400 : 1 (Typ.) (TM)
Viewing Angle： 85/85/85/85 (Typ.)(CR≥10)
Response： 30 (Typ.)(Tr+Td) ms
Good View at： Symmetry
Work Mode： VA, Normally Black, Transmissive
Color Depth：16.7M 71%(CIE1931)
Backlight：WLED, 50K hours, With LED Driver
Mass： 2.40Kgs (Max.)
Used for： Industrial Application, Medical Imaging,
Refresh Rate：60Hz
Touchscreen：Without
Signal Type： LVDS (2 ch, 8-bit), Connector , 30 pins
Voltage Supply：12.0V (Typ.)
Max. Ratings： Storage Temp.: -25 ~ 60 °COperating Temp.: 0 ~ 50 °C
