Panel Brand：ChiHsin
Panel Size：4.3 inch
Resolution：480(RGB)×272 , WQVGA
Display Area：95.04(W)×53.856(H) mm
Outline Size：105.5(W)×67.2(H) mm
Brightness：400 cd/m2 (Typ.)
Viewing Angle：70/70/55/70 (Typ.)(CR≥10)
Best View on：6 o’clock
Display Colors：16.7M
Frequency： 60Hz
Weight：60.0g (Typ.)
Panel Model：LR430RC9601
Panel Type：a-Si TFT-LCD , LCM
Pixel Format： RGB Vertical Stripe
Bezel Opening：-
Surface：Antiglare
Contrast Ratio：550:1 (Typ.) (TM)
Display Mode： TN, Normally White, Transmissive
Response Time：15/15 (Typ.)(Tr/Td)
Lamp Type： 10S1P WLED, Without Driver
Touch Screen：Embeded (4-wire Resistive)
Application： Portable Navigation, Pocket TV, MP4 PMP,
Signal Interface： Parallel RGB (1 ch, 8-bit), 45 pins , FPC
Input Voltage： 3.3V (Typ.)(VCC)
Environment： Operating Temp.: -20 ~ 70 °C ;Storage Temp.: -30 ~ 80 °C
