Manufacturer：AUO
Model Name： M185XW01 VH
Screen Size：18.5 inch
Screen Type：LCM ，a-Si TFT-LCD
Pixel Number：1366(RGB)×768 (WXGA)
Arrangement：RGB Vertical Stripe
Active Area(mm)： 409.8 × 230.4 (H×V)
Outline(mm)：430.37 × 254.6× 11 (H×V×D)
Bezel Area(mm)： 413.4 × 234.0 (H×V)
Treatment： Antiglare， Hard coating (3H)
Luminance：200 cd/m2 (Typ.)
Contrast Ratio：700 : 1 (Typ.) (TM)
Viewing Angle： 45/45/20/45 (Typ.)(CR≥10)
Response： 3.6/1.4 (Typ.)(Tr/Td) ms
Good View at： 6 o'clock
Work Mode： TN， Normally White， Transmissive
Color Depth：16.7M 65%(CIE1931)
Backlight：2 pcsCCFL， 50K hours， No Driver
Mass： 1.46Kgs (Typ.)
Used for： Desktop Monitor,
Refresh Rate：60Hz
Touchscreen：Without
Signal Type： LVDS (1 ch， 8-bit)， Connector ， 30 pins
Voltage Supply：5.0V (Typ.)
Max. Ratings： Storage Temp.: -20 ~ 60 °COperating Temp.: 0 ~ 50 °C
We use the following logistics services to deliver your order:
Yunexpress DDP: All customs duties and taxes are included. Delivery takes 6-12 working days.
DHL, UPS, FedEx: Delivery takes 2-4 working days.
Product condition: Brand New We can provide customized testing video upon request.
