Innolux N140BGE-E43 LCD panel

Brand：Innolux
Model：N140BGE-E43 (CMN1493)
Diagonal Size：14.0 inch
Type：a-Si TFT-LCD , LCM
Pixel Format：1366(RGB)×768[WXGA]
Configuration：RGB Vertical Stripe
Active Area：309.399(H)×173.952(V) mm
Outline Dim.：320.4(H)×205.1(V)×3.6(D) mm
Bezel Area：-
Treatment：Glare (Haze 0%), Hard coating (3H)
Luminance：220 cd/m2 (Typ.)
Contrast Ratio：650:1 (Typ.) (TM)
View Direction：6 o'clock
Response Time：3/7 (Typ.)(Tr/Td)
Viewing Angle：45/45/20/45 (Typ.)(CR≥10)
Operating Mode：TN, Normally White, Transmissive
Support Color：262K 45%(CIE1931)
Light Source：WLED, 15K hours, With LED Driver
Form Style： Flat (PCBA Flat, Depth 3.4~4.0mm)
Designed For： Laptop,
Frame Rate：60Hz
Touch Panel：Without
Interface Type： 30 pinseDP (1 Lane), Connector
Power Supply：3.3V (Typ.)
Environment： Operating Temperature: 0 ~ 50 °C ; Storage Temperature: -20 ~ 60 °C
