Innolux N156BGE-E11 LCD panel

Brand：Innolux
Model：N156BGE-E11 (CMN15B4) 4 Compatible
Diagonal Size：15.6 inch
Type：a-Si TFT-LCD, LCM
Pixel Format：1366(RGB)×768[WXGA]
Configuration：RGB Vertical Stripe
Active Area：344.232(H)×193.536(V) mm
Outline Dim.：359.3(H)×209.5(V)×5.5(D) mm
Bezel Area：349.58(H)×198.29(V) mm
Treatment：Antiglare, Hard coating (3H)
Luminance：200 cd/m2 (Typ.)
Contrast Ratio：500:1 (Typ.) (TM)
View Direction：6 o’clock
Response Time：3/8 (Typ.)(Tr/Td)
Viewing Angle：45/45/20/45 (Typ.)(CR≥10)
Operating Mode：TN, Normally White, Transmissive
Support Color：262K 60%(CIE1931)
Light Source：WLED, 15K hours, With LED Driver
Form Style：Wedge (PCBA Bent, Depth ≥5.2mm)
Designed For： Laptop,
Frame Rate： 60Hz
Touch Panel：Without
Interface Type： 30 pinseDP (1 Lane), Connector
Power Supply：3.3V (Typ.)
Environment：Operating Temperature: 0 ~ 50 °C; Storage Temperature: -20 ~ 60 °C
