Brand：NEC
Diagonal Size：3.5 inch
Pixel Format：240(RGB)×320[QVGA]
Active Area：53.64(H)×71.52(V) mm
Bezel Area：56.6(H)×75.0(V) mm
Luminance：50 cd/m2 (Typ.)
View Direction：-
Viewing Angle：-
Support Color：262K
Weight：39.5/42.0g (Typ./Max.)
Frame Rate：-
Model：NL2432DR22-11B
Type：a-Si TFT-LCD , LCM
Configuration：RGB Vertical Stripe
Outline Dim.： 66.2(H)×91(V)×4.7(D)mm
Treatment：Hard coating (3H)
Contrast Ratio：10:1 (Typ. light on); 10:1 (Typ. light off) (RF)
Response Time：15/17 (Typ.)(Tr/Td)
Operating Mode： TN, Normally White, Reflective
Light Source： WLED [2S2P]
Designed For： Handheld & PDA,
Touch Panel：Embeded (4-wire Resistive)
Interface Type： 45 pinsCMOS (1 ch, 6-bit), FPC
Power Supply： 3.0/5.25/15.0/-15.0V (Typ.)(VCC/VDD/VGON/VGOFF)
Environment： Operating Temperature: 0 ~ 50 °C; Storage Temperature: -20 ~ 70 °C; Vibration Level: 2.0G (19.6 m/s2)
We use the following logistics services to deliver your order:
Yunexpress DDP: All customs duties and taxes are included. Delivery takes 6-12 working days.
DHL, UPS, FedEx: Delivery takes 2-4 working days.
Product condition: Brand New We can provide customized testing video upon request.
