Panel Brand：NEC
Panel Size：6.5 inch
Resolution：640(RGB)×480 , VGA
Display Area：132.48(W)×99.36(H) mm
Outline Size：153(W)×118(H) mm
Brightness：1000 cd/m2 (Typ.)
Viewing Angle：80/80/80/80 (Typ.)(CR≥10)
Best View on：-
Display Colors：262K/16.7M40%(CIE1931)
Frequency： 60Hz
Weight：150/160g (Typ./Max.)
Panel Model：NL6448BC20-30F
Panel Type：a-Si TFT-LCD , LCM
Pixel Format： RGB Vertical Stripe
Bezel Opening：135.5(W)×102.4(H) mm
Surface：Clear, Hard coating (3H)
Contrast Ratio：800:1 (Typ.) (TM)
Display Mode： TN, Normally White, Transmissive
Response Time：3/15 (Typ.)(Tr/Td)
Lamp Type： 4 strings WLED , 70K hours , Without Driver
Touch Screen：Without
Application： Industrial Application, Outdoor High Brightness,
Signal Interface： LVDS (1 ch, 6/8-bit), 20 pins , Connector
Input Voltage： 3.3V (Typ.)
Environment： Operating Temp.: -30 ~ 80 °C ;Storage Temp.: -30 ~ 80 °C; Vibration Level: 2.0G (19.6 m/s2)
We use the following logistics services to deliver your order:
Yunexpress DDP: All customs duties and taxes are included. Delivery takes 6-12 working days.
DHL, UPS, FedEx: Delivery takes 2-4 working days.
Product condition: Brand New We can provide customized testing video upon request.
