Brand：PVI
Model：PA080XS4
Diagonal Size：7.9 inch
Type：a-Si TFT-LCD， LCM
Pixel Format：480(RGB)×468
Configuration：RGB Vertical Stripe
Active Area：161.28(H)×117.936(V) mm
Outline Dim.：172.4(H)×132(V)×6.9(D) mm
Bezel Area：164.5(H)×121.1(V) mm
Treatment：Antiglare
Luminance：350 cd/m2 (Typ.)
Contrast Ratio：350:1 (Typ.) (TM)
View Direction：-
Response Time：15/25 (Typ.)(Tr/Td)
Viewing Angle：50/50/15/35 (Typ.)(CR≥10)
Operating Mode：TN， Normally White， Transmissive
Support Color：Full color
Light Source：WLED[3S9P]， 30K hours， W/O Driver
Weight： 232±15g
Designed For： Automotive Display,
Frame Rate：-
Touch Panel：Without
Interface Type： 32 pinsTFT Specific Analog RGB， FPC
Power Supply：3.3/3.3/13.0/24.0/-8.0V (Typ.)(VCC/VDD1/VDD2/VGH/VEE)
Environment： Operating Temperature: -20 ~ 70 °C ; Storage Temperature: -30 ~ 80 °C
We use the following logistics services to deliver your order:
Yunexpress DDP: All customs duties and taxes are included. Delivery takes 6-12 working days.
DHL, UPS, FedEx: Delivery takes 2-4 working days.
Product condition: Brand New We can provide customized testing video upon request.
