Manufacturer：PVI
Model Name：PM070WL4
Screen Size：7.0 inch
Screen Type：LCM，a-Si TFT-LCD
Pixel Number：800(RGB)×480 (WVGA)
Arrangement：RGB Vertical Stripe
Active Area(mm)： 152.4 × 91.44 (H×V)
Outline(mm)：166.3 × 105.3× 12.75 (H×V×D)
Bezel Area(mm)： 156.0 × 95.0 (H×V)
Treatment： Antiglare， Hard coating (3H)
Luminance：330 cd/m2 (Typ.)
Contrast Ratio：400 : 1 (Typ.) (TM)
Viewing Angle： 60/60/40/55 (Typ.)(CR≥10)
Response： 15/25 (Typ.)(Tr/Td) ms
Good View at： 6 o'clock
Work Mode： TN， Normally White， Transmissive
Color Depth：262K
Backlight：3S11PWLED， 30K hours， No Driver
Mass： 318±15g
Used for： Industrial Application,
Refresh Rate：-
Touchscreen：Embeded (4-wire Resistive)
Signal Type： LVDS (1 ch， 6-bit)， Connector ， 20 pins
Voltage Supply：3.3V (Typ.)
Max. Ratings： Storage Temp.: -30 ~ 80 °COperating Temp.: -20 ~ 70 °C
We use the following logistics services to deliver your order:
Yunexpress DDP: All customs duties and taxes are included. Delivery takes 6-12 working days.
DHL, UPS, FedEx: Delivery takes 2-4 working days.
Product condition: Brand New We can provide customized testing video upon request.
