Panel Brand：PVI
Panel Model：PM070WX1
Panel Size：7.0 inch
Panel Type：a-Si TFT-LCD, LCM
Resolution：800(RGB)×480 , WVGA
Pixel Format：RGB Vertical Stripe
Display Area：152.4(W)×91.44(H) mm
Bezel Opening：156.0(W)×95.0(H) mm
Outline Size：165(W)×104(H)×6.5(D) mm
Surface：Antiglare
Brightness：400 cd/m2 (Typ.)
Contrast Ratio：400:1 (Typ.) (TM)
Viewing Angle：60/60/40/55 (Typ.)(CR≥10)
Display Mode：TN, Normally White, Transmissive
Best View on：-
Response Time：15/25 (Typ.)(Tr/Td)
Display Colors：262K
Lamp Type：1 pcsCCFL, 25K hours, Without Driver
Frequency：60Hz
Touch Screen：Without
Panel Weight： 175g
Application： Digital Photo Frame, Portable DVD Player,
Signal Interface： TTL (1 ch, 6-bit), 60 pins, FPC
Input Voltage：3.3/3.3/9.5/17.0/-8.0V (Typ.)(VCC/VDD1/VDD2/VGG/VEE)
Environment：Operating Temp.: -20 ~ 80 °C ;Storage Temp.: -30 ~ 80 °C
