Manufacturer：PVI
Model Name：PW036XS3
Screen Size：3.6 inch
Screen Type：LCM,a-Si TFT-LCD
Pixel Number：320(RGB)×234
Arrangement：RGB Vertical Stripe
Active Area(mm)： 78.24 × 45.864 (H×V)
Outline(mm)：89.47 × 58.09 (H×V×D)
Bezel Area(mm)： 80.84 × 48.46 (H×V)
Treatment： Antiglare
Luminance：250 cd/m2 (Typ.)
Contrast Ratio：350 : 1 (Typ.) (TM)
Viewing Angle： 55/55/15/35 (Typ.)(CR≥10)
Response： 10/25 (Typ.)(Tr/Td) ms
Good View at： 6 o’clock
Work Mode： TN, Normally White, Transmissive
Color Depth：Full color
Backlight：3S2PWLED, 10K hours, No Driver
Mass： 40.0±5.0g
Used for： VOIP Phone, Video Door Phone,
Refresh Rate：60Hz
Touchscreen：Without
Signal Type： TFT Specific Analog RGB, FPC , 30 pins
Voltage Supply：3.3/3.3/5.0/17/-12V (Typ.)(VCC/VDD1/VDD2/VGH/VEE)
Max. Ratings： Storage Temp.: -10 ~ 70 °COperating Temp.: 0 ~ 60 °C
We use the following logistics services to deliver your order:
Yunexpress DDP: All customs duties and taxes are included. Delivery takes 6-12 working days.
DHL, UPS, FedEx: Delivery takes 2-4 working days.
Product condition: Brand New We can provide customized testing video upon request.
