Panel Brand：TIANMA
Panel Model：TM020GDH41
Panel Size：2.0 inch
Panel Type：a-Si TFT-LCD, LCM
Resolution：176(RGB)×220 , QCIF+
Pixel Format：RGB Vertical Stripe
Display Area：31.68(W)×39.6(H) mm
Bezel Opening：32.68(W)×40.6(H) mm
Outline Size：38.03(W)×51.45(H)×3.15(D) mm
Surface：Clear, Hard coating (3H)
Brightness：220 cd/m2 (Typ.)
Contrast Ratio：500:1 (Typ.) (TM)
Viewing Angle：70/70/70/60 (Typ.)(CR≥10)
Display Mode：TN, Normally White, Transmissive
Best View on：6 o’clock
Response Time：20 (Typ.)(Tr+Td)
Display Colors：65K/262K 60%(CIE1931)
Lamp Type：1S3PWLED, 20K hours, Without Driver
Frequency：-
Touch Screen：Without
Panel Weight： 7.20g
Application： Mobile Phone,
Signal Interface： CPU, 36 pins, FPC
Input Voltage：(1.8/2.8)/2.8V (Typ.)(IOVCC/VCC)
Environment：Operating Temp.: -20 ~ 70 °C ;Storage Temp.: -30 ~ 80 °C
We use the following logistics services to deliver your order:
Yunexpress DDP: All customs duties and taxes are included. Delivery takes 6-12 working days.
DHL, UPS, FedEx: Delivery takes 2-4 working days.
Product condition: Brand New We can provide customized testing video upon request.
