Tianma TM026HDH02 LCD panel

Brand：TIANMA
Model：TM026HDH02
Diagonal Size：2.6 inch
Type：a-Si TFT-LCD, LCM
Pixel Format：240(RGB)×320[QVGA]
Configuration：RGB Vertical Stripe
Active Area：38.88(H)×51.84(V) mm
Outline Dim.：-
Luminance：240 cd/m2 (Typ.)
Contrast Ratio：500:1 (Typ.) (TM)
View Direction：6 o’clock
Response Time：25 (Typ.)(Tr+Td)
Viewing Angle：70/70/70/60 (Typ.)(CR≥10)
Operating Mode：TN, Normally White, Transmissive
Support Color：65K/262K 60%(CIE1931)
Light Source：WLED, W/O Driver
Weight：TBD
Designed For： Mobile Phone,
Frame Rate：-
Touch Panel：Without
Environment：Operating Temperature: -20 ~ 60 °C; Storage Temperature: -30 ~ 80 °C
