Brand：TIANMA
Diagonal Size：4.7 inch
Pixel Format：480(RGB)×272[WQVGA]
Active Area：103.68(H)×58.752(V) mm
Bezel Area：-
Luminance：280 cd/m2 (Typ.)
View Direction：12 o’clock
Viewing Angle：70/70/60/70 (Typ.)(CR≥10)
Support Color：16.7M 50% (CIE1931)
Weight：76.5g (Typ.)
Frame Rate： 60Hz
Model：TM047NBH011 Compatible
Type：a-Si TFT-LCD , LCM
Configuration：RGB Vertical Stripe
Outline Dim.： 114.3(H)×72.5(V)mm
Treatment：Antiglare, Hard coating (3H)
Contrast Ratio： 500:1 (Typ.) (TM)
Response Time：25 (Typ.)(Tr+Td)
Operating Mode： TN, Normally White, Transmissive
Light Source： WLED [5S2P] , 20K hours , W/O Driver
Designed For： Portable Navigation, Pocket TV, MP4 PMP,
Touch Panel：Embeded (4-wire Resistive)
Interface Type： 45 pinsParallel RGB (1 ch, 8-bit) + SPI, FPC
Power Supply： 3.3V (Typ.)
Environment： Operating Temperature: -20 ~ 60 °C; Storage Temperature: -30 ~ 70 °C
