Manufacturer：TIANMA
Screen Size： 5.7 inch
Pixel Number： 320(RGB)×240(QVGA)
Active Area(mm)：115.2 × 86.4 (H×V)
Bezel Area(mm)：-
Luminance：-
Viewing Angle：70/70/60/70 (Typ.)(CR≥10)
Good View at：6 o’clock
Color Depth：262K 50% (CIE1931)
Mass： –
Refresh Rate：60Hz
Model Name：TM057KDH05
Screen Type：LCM ,a-Si TFT-LCD
Arrangement：RGB Vertical Stripe
Outline(mm)：-
Treatment：Antiglare, Hard coating (3H)
Contrast Ratio： 500 : 1 (Typ.) (TM)
Work Mode： TN, Normally White, Transmissive
Response：20 (Typ.)(Tr+Td) ms
Backlight： WLED
Used for： Industrial Application,
Touchscreen：Without
Signal Type：Parallel RGB (1 ch, 6-bit), Connector, 40 pins
Voltage Supply： 3.3V (Typ.)
Max. Ratings： Storage Temp.: -30 ~ 80 °C Operating Temp.: -20 ~ 70 °C
