Innolux V315H3-LE3 LCD panel

{{ product.price_format }}
{{ product.origin_price_format }}
Stock:
Brand: Innolux
SKU:{{ product.sku }}
Model: {{ product.model }}

{{ variable.name }} : {{ variable.values[selectedVariantsIndex[variable_index]].name }}

{{ value.name }}

Quantity:




Brand:Chimei Innolux
Diagonal Size:31.5 inch
Pixel Format:1920(RGB)×1080[FHD]
Active Area:698.4(H)×392.85(V) mm
Bezel Area:705.4(H)×399.8(V) mm
Luminance:450 cd/m2 (Typ.)
View Direction:Symmetry
Viewing Angle:88/88/88/88 (Typ.)(CR≥20)
Support Color:16.7M 72% (CIE1931)
Weight:4.53Kgs (Typ.)
Frame Rate: 60Hz
Model:V315H3-LE3
Type:a-Si TFT-LCD , LCM
Configuration:RGB Vertical Stripe
Outline Dim.: 741.4(H)×435.8(V)mm
Treatment:Antiglare (Haze 11%), Hard coating (3H)
Contrast Ratio: 6000:1 (Typ.) (TM)
Response Time:8.5 (Typ.)(G to G)
Operating Mode: MVA, Normally Black, Transmissive
Light Source: WLED, 30K hours , With LED Driver
Designed For: TV Sets,
Touch Panel:Without
Interface Type: 51 pinsLVDS (2 ch, 8-bit), Connector
Power Supply: 12.0V (Typ.)
Environment: Operating Temperature: 0 ~ 50 °C; Storage Temperature: -20 ~ 60 °C

We use the following logistics services to deliver your order:

Yunexpress DDP: All customs duties and taxes are included. Delivery takes 6-12 working days.

DHL, UPS, FedEx: Delivery takes 2-4 working days.

Product condition: Brand New We can provide customized testing video upon request.
